Johnson Controls M9220-BGC-3 Damper Actuator 2 Position 2 Switch On/Off Spring Return 177 IN-LB 24V

Special Price $408.51 Regular Price $453.45
In stock
SKU
M9220-BGC-3
The Johnson Controls M9220-BGC-3 Damper Actuator is an option for controlling air dampers in HVAC systems, This more durable device has a high-strength thermoplastic structure and directly attaches to damper shafts, whether square or round for easy installation. It employs a two-position (on/off) control signal with 24V AC or DC power, the same as the M9220-BGA-3. When activated, it rotates the damper shaft to the desired open position, as you will see later in this document. Two switches are incorporated into the structure of the device as additional control elements. These switches provide electrical feedback as to the position of the damper; open or closed.
Manufacturer:
https://www.partshnc.com/media/catalog/product/p/a/partshnc_johnson_controls_parts_24v_sr_2pos_actr_2sw_177inlb_m9220bgc3.jpeg

Specifications

  • Range Of Temperature: -40°F to 131°F
  • Voltage: 24 VAC, 24 VDC
  • Torque Rating: 177 LB-IN
  • Fail-Safe Mode: Spring Return
  • IP Rating: IP54
  • Mounting: Direct Coupled
  • Feedback: 0-10 VDC, 2-10 VDC
  • Electrical Connections: Cable
  • Control Signal: Two Position (On/Off)
  • Shaft Size: Square 3/8"-1/2", Round 1/2"-3/4"
  • Switches: 2
  • Shaft Rotation: By Wiring
  • Weight: 7.26 Lbs
Manufacturer Name: Johnson Controls
Product Number: M9220-BGC-3
OEM Part Number: M9220-BGC-3
Product Description: 24V S/R 2Pos Actr 2Sw 177Inlb
Weight:7.26lbs/3293.08g
